ZX37T
ZX37T
Spider Lifts
ZX37T

ZX37T spider lift uses the engine as the main power, with plug-in power system and electric emergency system, connecting to 220V AC for operation, with higher flexibility, and stronger endurance. It has compact design, trackless chassis offers excellent off-road and transit performance, and the two-section retractable jib provides higher working height and end flexibility in the industry. It satisfies various construction demands, especially in the indoor operation of large buildings such as airport railway stations, science and technology museums, shopping malls, stadiums and hotels; The chassis width is small and the weight is light, able to enter various narrow channels and narrow indoor space for aerial work; Small ground pressure, strong cross-country ability, automatic leg leveling, ideal for indoor and outdoor complex working conditions. It features wide range of applications, with strong site adaptability and operational flexibility.

Advantage introduction
    • 1.2m ultra-narrow width, quick-change work platform, easy access to compact spaces.

    • 120kg/230kg/330kg various loads for various working conditions
    • Engine + Plug-in work mode for multiple applications

    • Symmetric layout boom, great structural rigidity, and small boom deflection

    • Telescopic jib for flexible boom end

    • Non-marking rubber track suitable for all terrains

More Advantages
Metric / Imperial
Size
Up and over height
Performance
Power
Battery
Charger
Drive motor
Lift motor
Tire
Weight
Work height 37.3m
Platform height 35.3m
Horizotal outreach 15.7m
Below ground reach 5.7m
A-Stowed length(w/platform) 7.9m
D-Stowed length(w/o platform) 7.9m
B-Stowed width 1.2m
C-Stowed length 1.99m
E-Platform length 1.8m
F-Platform width 0.7m
G-Platform height 1.1m
H-Crawler Size(length × width) 2.43m×0.3m
I-Max length w/outrigger extending(standard) 5.55m
L-Max width w/outrigger extending(standard) 5.4m
K-Max length w/outrigger extending(narrow) 7.35m
J-Max width/outrigger extending(narrow) 2.68m
Outrigger pad size(diameter) 0.24m*0.2m
Approach angle 19°
Departure angle 24°
Platform capacity 230kg/330kg(restricted)/120kg(unrestricted)
Drive speed 2km/h
Gradeability 19.8°/36%
Allowable tilting angle when driving 8.5/15%
Turntable swing 360°continuous
Platform rotation ±90°
H-tail swing 0m
Max leveling angle 13°
Max wind speed 12.5m/s
Engine Yanmar
Auxiliary power Electric pump
Hydraulic tank capacity 110L
Crawler type Non-marking rubber track
Gross weight 8400kg
Ground pressure when driving 36.9N/㎡
Ground pressure when working(standard) 2.8N/㎡
Ground pressure when working(narrow) 4.26N/㎡
Pressure on single outrigger when working 47KN
Work height 122ft 5in
Platform height 115ft 10in
Horizotal outreach 51ft 6in
Below ground reach 18ft 8in
A-Stowed length(w/platform) 25ft 11in
D-Stowed length(w/o platform) 25ft 11in
B-Stowed width 3ft11in
C-Stowed length 6ft 6in
E-Platform length 5ft 11in
F-Platform width 2ft 4in
G-Platform height 3ft 7in
H-Crawler Size(length × width) 7ft 12in×12in
I-Max length w/outrigger extending(standard) 18ft 3in
L-Max width w/outrigger extending(standard) 17ft 9in
K-Max length w/outrigger extending(narrow) 24ft 1in
J-Max width/outrigger extending(narrow) 8ft 10in
Outrigger pad size(diameter) 9ft×7ft
Approach angle 19°
Departure angle 24°
Platform capacity 507lb/728lb(restricted)/265lb(unrestricted)
Drive speed 1.25mph
Gradeability 19.8°/36%
Allowable tilting angle when driving 8.5/15%
Turntable swing 360°continuous
Platform rotation ±90°
H-tail swing 0m
Max leveling angle 13°
Max wind speed 28mph
Engine Yanmar
Auxiliary power Electric pump
Hydraulic tank capacity 29.1 us gal
Crawler type Non-marking rubber track
Gross weight 18519lb
Ground pressure when driving 36.9N/㎡
Ground pressure when working(standard) 2.8N/㎡
Ground pressure when working(narrow) 4.26N/㎡
Pressure on single outrigger when working 47KN
