Our product is equipped with a structurally optimized full penetration welded cross-section frame, a light and wear-resistant cargo compartment, customized high-load axles and gearboxes for mines, which can improve the lifespan and load capacity of the truck.
The front suspension is a five-link hydro pneumatic spring rigid axle suspension, the middle and rear suspension is a parallel-mounted two-axle five-link hydro pneumatic spring rigid axle balance suspension. The connecting rod bearing adopts maintenance-free joint bearings, which has better performance on carrying reliability, maintenance convenience and comfort.
Driving comfort: Full Hydraulic Steering System; Wide-body cab of mine; Adjustable damping driver seat; Composite floor structure composed of thickened steel plate and rubber sponge; Multimedia-one computer has the functions of radio, Bluetooth, GPS, reversing image and USB expansion.
Convenient maintenance: Maintenance-free oscillating bearing and shaft sleeve; The front suspension designed with pedal is more convenient maintance.
It is a product tailor-made for open-pit mines;
Full penetration welded cross-section frame;
More lifespan and load capacity of the truck；
20% higher braking torque for the whole vehicle；
Greatly meets the low-speed and heavy-duty requirements of users;
| Main Parameters | Unit | Value |
| Curb Weight | kg | 34000 |
| Rated Payload | kg | 80000 |
| Max. Speed | km/h | 42 |
| Max. Gradeability | % | 29 |
| Min. Turning Radius | m | 12 |
| Tires/ | 16.00R25 | |
| Axle Payload | t | 35+45+45 |
| Engine Model | / | YC6K560-GT30 |
| Engine Displacement | L | 12.939 |
| Emission Standard | / | GB20891-2014Ⅲ |
| Rated Power | kW/rpm | 412/1900 |
| Max. Torque | N.m/rpm | 2400/(1100-1500) |
| Gearbox Model | / | FAST 8DS260 |
| Capacity | m' | 45/53(SAE2:1) |
| Curb Weight | 34000kg |
| Rated Payload | 80000kg |
| Body volume | 45m³/53m³(SAE 2:1) |
| Engine power | 412kW(560HP) |
| Rated Power | 412/1900 kW/rpm |
| Engine Model | YC6K560-GT30 |
