Products-ZOOMLION

FH88-100

Combine Harvester

FH88-100

Feeding capacity 4kg/s

88/100 HP four cylinder turbocharged engine with 20% torque reserve

2/2.2m large header, feeding speed of 487.3rpm

45HST + high-strength 85 gearbox

High ground clearance, better to pass the mud field

Longitudinal axial threshing cylinder

Large granary+high hydraulic unloading

Corn header and kit as option

Get Pricing

Advantage introduction

88/ 100 hp high-quality engine, with strong power, large torque reserve
HST of 45 displacement is matched with the 85 gearbox, with high gearing efficiency
With the independent integrated re-threshing roller, with strong adaptability and better re-threshing effectiveness
High rotating unloading and multi-directional unloading can meet the needs of different regions

More Advantages

Param

Rated HP	65(88)kw/73.5(100)kw
Feeding capacity	-
Cutting Width	-
Rated speed	2400RPM
Gauge	1250mm
Minimum ground clearance	325mm
Threshing Drum (Diameter×Length)	φ620×2000mm
Main roller(O.D.×length)	-
Auxiliary roller(O.D.×length)	-
Operation Productivity	0.741-1.729hm²/h
