Famous and high-quality engine of National Emission Standard II
Double-acting clutch that works independently
Enhanced chassis and waterproof wiring harness 12F+12R shuttle shift
enhanced double-speed power output
partial separated lifter with auxiliary oil cylinder
Adjustable rear track and extra-large fuel tank
Brand-name and high-quality engine of National Emission Standard ll isselected, which is powerful, reliable and economical.
The double-acting clutch that works independently is applied, which is madeof imported friction material, with large torque reserve coefficient and highreliability.
The enhanced chassis provides better reliability and service life;The waterproof wiring harness makes the machine more suitable for paddyoperation.
The 12F+12R shuttle shift is smoother and more comfortable, whichimproves the continuous shifting and thus the efficiency.
The enhanced double-speed power output can be matched with moremachines and tools to meet the needs of various operations.
The partial separated lifter with auxiliary oil cylinder has large lifting force, forcecontrol and better operation effect.
The rear track is adjustable to meet various agronomic requirements; The fuel tank of large capacity works more efficiently.
The whole machine is tightly sealed without "three leaks".
Model | Unit | RK504-A | RK704-A |
Overall dimension (L×W × H) | mm | 3980×1750×2620 | 4030×1728×2840 |
Wheelbase | mm | 2020 | 2040 |
Minimum mass during operation | kg | 2335 | 2385 |
Minimum ground clearance | mm | 320 | 355 |
Engine emission | / | National II | |
Rated power | kw | 36.8 | 51.5 |
Fuel consumption rate | g/kW•h | ≤242 | ≤238 |
Cluth type | / | Dry type, independent control double action | |
Number of gears of the gearbox | / | 12F+12R | |
Tyre size (front wheel/rear wheel) | / | 8.3-20/12.4-28 | 8.3-24/14.9-30 middle-pattern tyre |
8.3-20/14.9-28 | |||
Type of hydraulic lifting system | / | Lifting device with partial separated units | |
Maximum lifting capacity | kN | ≥8.8 | ≥15 |
Tillage control method | / | Independent force position adjustment and floating control | |
Hydraulic output multiway valve | / | 2 groups | |
Hydraulic hitch | / | Three-point rear suspension, Class I | |
Traction force | KN | 12.5 | 14 |
Power output speed | r/min | 540/1000 | 540/760 |
Safety shelf or cab | / | Safety shelf + sunshade |
