Four Wheel drive
90/110HP Four-cylinder high-pressure common-rail National III engine
Fuel atomization effect is good,more fuel-efficient
Cabin upgrade,more comfortable operation
16F+8R Meshing sleeve gearshift
Hydraulic-driven steering system
The rear track adjustable
The Yuchai high-pressure common rail engine is selected, which has an excellent fuelatomization effect and is powerful and economical.
The enhanced clutch that works independently is applied, which is made of importedfriction material, with large torque reserve coefficient and high reliability.
The transmission system and hydraulic system adopt high-quality three-purpose oilto ensure the stable operation of the whole machine.
The double cylinder strong pressure lifter of type ll suspension is applied to matchwith a variety of composite machineries, quick Lauka hooking, convenient and fast.
The standard 150L fuel tank is selected, which has high operating efficiency to workall day at full load.
Three sets of hydraulic output have wide adaptability, which can meet the operationalneeds of folding rake, flip plow and other machineries.
The high-end plug-in parts are adopted, which is more durable and safer.
The speciallow-temperature battery ensures normal operation in extreme environments.
The 4.3-inch intelligent digital display instrument can monitor the workingcondition of the whole machine at any time.
The luxury four-pillar cab with air conditioner is dustproof, noise- reducing.and heat insulating.Adjustable steering wheel and mechanical suspending seats are equipped.
Model | Unit | RN904Pro/RN1104Pro | RN904/RN1104(2025 new) |
Overall dimensions (L×W×H) | mm | 4600×2095×2950 | |
Wheelbase | mm | 2350 | |
Min. operating mass | kg | 4300 | |
Min. ground clearance | mm | 435 | |
Engine emission | / | National Ⅲ | |
Calibration power | kW | 67/81 | |
Fuel consumption rate | g/kW•h | ≤230 | |
Clutch type | / | Dry, independent control double action | |
Number of gears | / | 16F+8R | 12F+12R |
Tire specification (front wheel/rear wheel) | / | 12.4-24/16.9-34 | |
Type of hydraulic lifting system | / | Independent adiustment of mechanical force and position/ High pressure | |
Max. pull force | kN | ≥25 | 50 |
Tillage depth control method | / | Position adjustment and floating control | Draft control |
Hydraulic-output multiway valve | / | 3 groups | |
Hydraulic hitch | / | Three-point rear suspension, ClassII | |
Calibration traction force | kN | ≥34.5/35.5 | |
PTO power output | kW | 56.3/69 | |
PTO speed | r/min | 540/1000 | |
Safety shelf or cab | / | A/C cab |
Wheelbase | 2350mm |
Minimum ground clearance | 435mm |
Rated power | 66/81kW |
Number of gears of the gearbox | 16F+8R Meshing sleeve gearshift |
Maximum lifting capacity | ≥25KN |
Traction force | ≥34.5/35.5KN |
PTO output power | 56.3/69KW |
Power output speed | 540/1000 |
