ZA26J

ZA26J

Diesel Articulating Boom Lifts

ZA26J

Diesel powered articulating boom lifts for precise position and extreme flexibility.

Get Pricing

Advantage introduction

Provide heavy lifting of 250kg load for 28% higher efficiency
Build-in multiple pressure control leveling system to enhance stability
Precise load sensing system to improve overload safety operations
Deadweight Lowering System for smooth operation and energy efficiency
Outstanding below ground reach of 5.7m

More Advantages

Metric / Imperial

Size

Performance

Power

Tire

Weight

Work Height	28.2m
Platform Height	26.2m
Horizontal Outreach	19.4m
Up and Over Height	9.48m
A - Stowed Length	11.75m
B - Stowed Width	2.49m
C - Stowed Height	2.82m
D - Platform Length	2.44m
E - Platform Width	0.91m
F - Wheelbase	3.05m
G - Ground Clearance	0.42m

Platform Capacity	250kg
Drive Speed	5.0km/h
Gradeability	45%(24°)
Axles Oscillation	0.2m
Turning Radius (Inside)	3.14m
Turning Radius (Outside)	6.48m
Turntable Swing	360°continuous
Platform Rotation	±90°
H-Tail Swing	1.422m
Max. Working Slope	5°
Max. Wind Speed	12.5m/s

Diesel Engine	Kubota V2607-CR-TI-EW02/Kubota V3307-DI-T-MAR1-ET02

Fuel Tank Capacity	150L
Auxiliary Power	12V
Control Voltage	12V
Hydraulic System Capacity	263L
Hydraulic Tank Capacity	180L

Type	Foam-filled Tires

Gross

18800kg

Work Height	92ft 6in
Platform Height	85ft 11in
Horizontal Outreach	63ft 8in
Up and Over Height	31ft 1in
A - Stowed Length	38ft 7in
B - Stowed Width	8ft 2in
C - Stowed Height	9ft 3in
D - Platform Length	8ft
E - Platform Width	2ft 12in
F - Wheelbase	10ft
G - Ground Clearance	1ft 5in

Platform Capacity	550lb
Drive Speed	3.11mph
Gradeability	45%(24°)
Axles Oscillation	8in
Turning Radius (Inside)	10ft 4in
Turning Radius (Outside)	21ft 3in
Turntable Swing	360°continuous
Platform Rotation	±90°
H-Tail Swing	4ft 8in
Max. Working Slope	5°
Max. Wind Speed	28mph

Diesel Engine	Kubota V2607-CR-TI-EW02/Kubota V3307-DI-T-MAR1-ET02

Fuel Tank Capacity	39.6(us gal)
Auxiliary Power	12V
Control Voltage	12V
Hydraulic System Capacity	69.5(us gal)
Hydraulic Tank Capacity	47.6(us gal)

Type	Foam-filled Tires

Gross

41447lb
