ZA20JEH
ZA20JEH
Range-Extended Hybrid Articulating Boom Lifts
ZA20JEH
ZA20JEH provides greater work height of 21.38m and lift capacity of 250kg (550 lb)/360kg(790 lb). Its excellent energy management system improves running time and extends battery life. Accurate and efficient traveling AC drive system and on-board motion AC drive system provides strong power, stable control and maintenance-free motor.


Advantage introduction

    · 6kw large power range extender provides power in low electric quantity for long working hours;

    · Fast lift system directly lowers the boom from the highest position to the ground, no need to fold the boom to improve work efficiency;

    · Independent auxiliary power system for more secure application;

    · Large reduction ratio reducer provides stronger gradeability;Safe and reliable lithium battery power system equipped with BMS low-tem-perature heating and low-temperature charging current control functions improves battery life by 30% and adapts to -20℃ cold environment.


More Advantages
Metric / Imperial
Performance
Power
Tire
Weight
Platform Capacity 250/360kg
Drive Speed 5.2km/h
Gradeability 45%
Axles Oscillation 0.2m
Turning Radius (Inside) 2.78m
Turning Radius (Outside) 5.49m
Turntable Swing 360°continuous
Platform Rotation ±90°
H-Tail Swing 0.64m
Max. Working Slope 3°/5°
Max. Wind Speed 12.5m/s
Battery 48V/314Ah Li-ion battery(Li)
Charger 48V/60A
Drive Motor AC32V
Lift Motor AC32V
Auxiliary Power 12V DC
Hydraulic Tank Capacity 75L
Type Foam-filled tire
Gross 9750kg
Platform Capacity 550/790lb
Drive Speed 3.23mph
Gradeability 45%
Axles Oscillation 8in
Turning Radius (Inside) 9ft 1in
Turning Radius (Outside) 18ft
Turntable Swing 360°continuous
Platform Rotation ±90°
H-Tail Swing 2ft 1in
Max. Working Slope 3°/5°
Max. Wind Speed 28mph
Battery 48V/314Ah Li-ion battery(Li)
Charger 48V/60A
Drive Motor AC32V
Lift Motor AC32V
Auxiliary Power 12V DC
Hydraulic Tank Capacity 19.8(us gal)
Type Foam-filled tire
Gross 21494lb
