ZDG650
ZDG650
Hydraulic Diaphragm Wall Grab
ZDG650
Advanced technology, excellent performance, reliable quality, easy operation

ZDG650 is a kind of equipment for groove-shaping to meet moderately or very demanding piling requirements.

It uses mature undercarriage technology with Zoomlion's consistent excellence, such as real-time vertical adjustment, bucket's free swing and oil hose burst proof, etc.

With optional Rexroth winches with free-fall function, it realizes drilling to hard soil through great free-fall impulse force and easily tackles the piling barriers brought with the hard soil.

It realizes drilling to hard soil through great free-fall impulse force and easily tackles the piling barriers brought with the hard soil.

ZDG650's grooving width ranges from 800mm to 1500mm and its grooving m depth gets 80m.

It's the best equipment choice for meeting moderately or very demanding piling requirements.

  • 660 kN
    Max. hoisting force
  • 1.5 m
    Max. wall thickness
  • 80 m
    Max. wall depth
  • 5600 mm
    Max. working radius
  • 660 kN
    Max. hoisting force
  • 1.5 m
    Max. wall thickness
  • 80 m
    Max. wall depth
  • 5600 mm
    Max. working radius
Advantage introduction
    • Super large closing force, strong cutting ability of bucket body;The weight of the bucket body is increased, and the modular counterweight is equipped,  the weight combination is convenient and diverse;Swing type front and back deviation correction has little influence on groove wall, high deviation correction efficiency and high groove forming accuracy;The bucket body ± 180 ° rotation function can be selected to solve the construction problem of "+" and "L" groove of building accessories.The reel depth adaptive follow-up function can effectively improve the follow-up performance and hose life;High rigidity mast type large triangle luffing structure, heavy slewing support design, high working stability;There is no dead angle when the multi-directional video monitoring equipment rotates and walks;The hydraulic leakage monitoring of the whole machine ensures the safety of the grab hydraulic system;Function button panel, common operation within reach; "Zoomlion e-housekeeper", mobile app to facilitate understanding of equipment construction information;

More Advantages
Operating parameters
Main winch
Grab system
Engine
Undercarriage
Overall main machine
Max. hoisting force 660kN
Max. wall thickness 1.5m
Max.wall depth 80m
Max. Working radius 5600mm
Max. line pull force 2×330kN
Max. Lifting speed 60m/min
Djameter of wire rope 36mm
Size of buckets available 0.8/1/1.2/1.5m
Panel length 2.8m
Weight of Grab 32t
Bucket capacity 1.2~2.3m3
Height of grab 9m
Grab cylinder force 2000 (35 Mpa)kN
Turning angle of grab Optional
Panel thickness 760mm
Model Cummins QSM11
Rated power of engine 298/2000kW/rpm
Emission standard Stage Il
Displacement of engine 11L
Distance of tracks center 5582mm
Distance of tracks(min.-max.) 3450~4800mm
Width of track shoe 800mm
Traction force 705kN
Overall dimension(length, width and height) 10760*4800*18154mm
Overall dimension(length, width and height) 14795*3750*3477mm
Mast structure Box-shaped arm
Slewing radius of the rear 4584mm
Operation weight(without grab) 126t
Max. hoisting force 660kN
Max. wall thickness 1.5m
Max.wall depth 80m
Max. Working radius 5600mm
Max. line pull force 2×330kN
Max. Lifting speed 60m/min
Djameter of wire rope 36mm
Size of buckets available 0.8/1/1.2/1.5m
Panel length 2.8m
Weight of Grab 32t
Bucket capacity 1.2~2.3m3
Height of grab 9m
Grab cylinder force 2000 (35 Mpa)kN
Turning angle of grab Optional
Panel thickness 760mm
Model Cummins QSM11
Rated power of engine 298/2000kW/rpm
Emission standard Stage Il
Displacement of engine 11L
Distance of tracks center 5582mm
Distance of tracks(min.-max.) 3450~4800mm
Width of track shoe 800mm
Traction force 705kN
Overall dimension(length, width and height) 10760*4800*18154mm
Overall dimension(length, width and height) 14795*3750*3477mm
Mast structure Box-shaped arm
Slewing radius of the rear 4584mm
Operation weight(without grab) 126t
