12F+12R independent shuttle shift
3600kg extremely light weight
500mm high ground clearance
55° super steering Angle
Minimum steering radius only 3.7m
Full hydraulic power steering system
It is featured by 500mm ultra high ground clearance, drive system without wading, small driving resistance, and excellency in paddy field passing;
The car body is 3600kg, not afraid of extreme environment, easy to control the wet rotten field, and not trapped during own operation;
12F+12R shuttle synchronize shift on wide speed range. Flexible use of high efficiency meets the needs of various operations;
55° large steering angle, minimum turning radius of 3.7m, flexible and significantly improving work efficiency.
Model | Unit | RV904/954/1104 |
Overall dimension (L×W × H) | mm | 4647×2031×2800 |
Wheelbase | mm | 2350 |
Minimum mass during operation | kg | 3600 |
Minimum ground clearance | mm | 500 |
Engine emission | / | National III |
Rated power | kw | 66/70/81 |
Fuel consumption rate | g/kW•h | ≤235 |
Cluth type | / | Dry type, single action |
Number of gears of the gearbox | / | 12F+12R independent shuttle shift |
Tyre size (front wheel / rear wheel) | / | 9.5-24/16.9-30 |
Type of hydraulic lifting system | / | Split type |
Maximum lifting capacity | KN | 23 |
Tillage control method | / | Position adjustment and floating control |
Hydraulic output multiway valve | / | 2 groups |
Hydraulic hitch | / | Three-point rear suspension, Category II |
Traction force | KN | 28 |
PTO output power | kW | 65.4-81 |
Wheelbase | 2350mm |
Minimum ground clearance | 500mm |
Rated power | 66/81kW |
Number of gears of the gearbox | 12F+12R independent shuttle shift |
Maximum lifting capacity | 23kN |
Traction force | 28kN |
PTO output power | 65.4/81kW |
Power output speed | 540/720RPM |
