Main boom operating mode

Max. lifting moment

t·m

1201

Max. lifting capacity

t

220

Main boom length

m

16～85

Luffing jib operating mode

Max. lifting capacity

t

71.8

Luffing jib length

m

22～52

Longest main boom + jib

m

55+52

Fixed jib operating mode

Max. lifting capacity

t

52.2

Fixed jib length

m

13～31

Longest main boom + jib

m

61+31/70+13

Speed parameter

Max. rope speed of main hoisting mechanism（outmost layer）

m/min

140

Max. rope speed of secondary hoisting mechanism（outmost layer）

m/min

140

Max. rope speed of derricking mechanism（outmost layer）

m/min

49

Max. slewing speed

r/min

1.16

Max. crawling speed

km/h

1.2

Dead weight of the whole crane (16m basic boom with hook for 200t, 64t rear counterweight)

t

174

Transport parameters of basic machine

Transport weight (including main boom pivot section)

t

40.3

Transport dimension

mm

17600×3000×3320

Track gauge × contact length of track × width of track pad

mm

6300×7860×1000

Gradeability

％

30

Average ground pressure

MPa

0.109

Counterweight

Rear counterweight

t

64/74/84

Central ballast

t

28

Engine

Model

/

WP10G336E344

Rated power/speed

kW/rpm

247/1900

Emission standard

/

ChinaⅢ
