Product Description

1. The lifting performance is industry-leading at the 70Tm level.

2. Eight-section telescopic boom, with a working range of up to      20.6m. It adopts 960 high-strength material, has good rigidity, is      lightweight, and has a mature production process.

3. The double four-link mechanism can achieve operations within a      large elevation angle of 80° and a reverse angle of -15°, meeting the      operation requirements in narrow spaces.

4. 8.6m two-stage large-span telescopic outriggers make the      operation more stable.

5. The sequential telescopic cylinder realizes strict sequential      extension. There is no risk of oil leakage in the cylinder caused by      overpressure, ensuring safe and reliable operation.

6. The post-valve compensation proportional control system has      good micro-movement performance and good combined actions. Cooperating      with the re-telescopic valve, the operation efficiency is high.

7. Standard with an innovative hydraulic overload protection      design, making telescopic operation with load safer. An electrical      overload alarm system is available as an option.

8. Standard with an integrated control panel, enabling control of      start, stop, horn, lights, etc., and the operation is more convenient.

9.     Configurable Options, including winch, manual fly jib, fly boom, remote control and other functions.

10. Based on the existing platform of truck-mounted cranes, the key      and important components have high universality, strong      interchangeability, complete supporting facilities, and convenient      after-sales maintenance.
