National III 300hp Yuchai engine
240hp and 185hp light-load and fuel-saving working mode
Double longitudinal axial flow threshing separation technology
6.5° inclination angle of the upper sieve
8.8m3 grain tank and 600L fuel tank
Famous brand walking large pump and front and rear motors
The 300hp engine uses a Bosch fuel system, a 250bar high explosion pressure cylinder,and a 2000bar fuel system, which can easily cope with complex field conditions andwalking conditions, providing continuous and stable power for harvesting work.
High efficiency and low loss double bullet threshing and separation systemThe system can be widely used in the harvesting of various crops such as wheat, cormnsoybeans, and rice.
Our company's flexible threshing technology can achieve a wheatharvest loss rate of less than 0.4% and a com harvest grain breakage rate of less than 1%Large-capacity grain tank, high-speed grain unloading.
The electronically controlled opening and closing large grain tank has a capacity of9000Lwhich reduces the time and frequency of grain unloading during harvesting, increasesthe operating area per unit time, and makes work more efficient.Floating profile modelling.
The bridge can float left and right, ensuring fast cutting and minimizing feeding losseseven when working on a 10° slope.
Intelligent air separation and threshing systemThe high-frequency vibrating screen box is independently developed by Zoomliontop-level structural team, using 900Mpa high-strength steel material and high fatigueresistance welding technology.
Zoomlion unique H-drive chassis system has extremelystrong passability and adaptability.
The core hydraulic time-sharing four-wheel drive system provides precise control forthe torque distribution switch between the front and rear axles, so that the vehicle'spower distribution in different terrains always remains in the optimal state.
Header and bridge ●Standard ○ Optional | |
Electronic floating | ● |
Planetary gearbox | ● |
Wheat header 6.1m | ○ |
Flexible header 5.6m | ○ |
Corn header 6-row 8-row | ○ |
Header trailer | ● |
Bridge reversal | ● |
Threshing and cleaning | |
Cutting flow + double longitudinal roller | ● |
Number of threshing rollers | 2 |
Longitudinal axial flow main separation roller | ● |
Roller size (mm) | Ф480×3180 |
Grid type concave plate screen | ● |
Cleaning area (m²) | 4.3 |
Re-threshing | ● |
Centrifugal fan | ● |
Grain tank | |
Capacity(L) | 9000 |
Unloading speed(L/s) | 55 |
Traveling system | |
Guide wheel tire specifications | 14.9R24 (8-level) |
Drive wheel tire specifications | 28L-26 (16-level) |
Wheelbase | 3586 |
Power system | |
Rated power (kW) | 221 |
Rated speed (r/min) | 2200 |
Fuel tank capacity (L) | 600 |
Whole machine | |
Overall dimensions (mm) | 8100×3800×3975 |
Weight (kg) | 12650 |
Minimum ground clearance (mm) | 380 |
