ZA16JERT-Li

ZA16JERT-Li

Range-Extended Hybrid Articulating Boom Lifts

ZA16JERT-Li

RT Electric Articulating Boom Lifts feature strong rough terrainability, providing exceptional off-road performance and quiet working conditions around jobsites.

Get Pricing

ZA16JERT-Li

video

17.8 m

Work Height
9.72 m

Horizontal Outreach
8 m

Up and Over Height
250 kg

Platform Capacity

17.8 m

Work Height
9.72 m

Horizontal Outreach
8 m

Up and Over Height
250 kg

Platform Capacity

ZA16JERT-Li

video

Advantage introduction

Center layout, great structural rigidity, andsmall boom deflection
Accurate and efficient traveling AC drivesystem provides strong power and stablecontrol, motor maintenance-free
Electrical off-road articulating boom lift of16m height with strong power suits forcomplicated working conditions
4WD provides strong power, ideal foroff-road application
Advanced dual control system (valvecontrol + pump control) offers aenergy-saving, smooth and efficientcontrol
Large-capacity lithium battery featureslong-lasting battery life, and number ofcharge and discharge cycles reaches 2500times, the whole life cycle is mainte-nance-free, and a 5-year warranty isprovided (ZA16JERT-Li Only)

More Advantages

Metric / Imperial

Size

Performance

Power

Tire

Weight

Features

Work Height	17.8m
Platform Height	15.8m
Horizontal Outreach	9.72m
Up and Over Height	8m
A - Stowed Length	7.7m
B - Stowed Width	2.3m
C - Stowed Height	2.23m
D - Platform Length	1.83m
E - Platform Width	0.76m
F - Wheelbase	2.36m
G - Ground Clearance	0.36m

Platform Capacity	250kg
Drive Speed	5.5km/h
Gradeability	45%(24°)
Axles Oscillation	0.20m
Turning Radius (Inside)	2.06m
Turning Radius (Outside)	4.78m
Turntable Swing	360° non-continuous
Platform Rotation	±90°
H-Tail Swing	0.2m
Max. Working Slope	5°
Max. Wind Speed	12.5m/s

Battery	48V/315Ah Li-ion battery
Charger	48V/60A
Drive Motor	AC 32V
Lift Motor	AC 32V
Auxiliary Power	12V DC Electrical pump
Hydraulic Tank Capacity	30L

Type	33×12 Foam-filled tire

Gross

7300kg

Standard

Proportional control

All motion alarm

Flashing beacon

Self-closing entry gate

Emergency descent system

Emergency stop button

Auto-leveling system

On-board diagnostic system

Over tilt protection system

Oscillating axle (ZA20JE)

Load sensing system

4.3' LED display

Horn

Option

AC power to platform

Airline to platform

2.44×0.91m/8ft×2.98ft work platform（ZA20JE）

Non-marking tire

Work Height	58ft 5in
Platform Height	51ft 10in
Horizontal Outreach	31ft 11in
Up and Over Height	26ft 3in
A - Stowed Length	25ft 3in
B - Stowed Width	7ft 6in
C - Stowed Height	7ft 4in
D - Platform Length	6 ft
E - Platform Width	2ft 6in
F - Wheelbase	7ft 9in
G - Ground Clearance	1ft 2in

Platform Capacity	550 lb
Drive Speed	3.2mph
Gradeability	45%(24°)
Axles Oscillation	8in
Turning Radius (Inside)	6ft 9in
Turning Radius (Outside)	15ft 8in
Turntable Swing	360° non-continuous
Platform Rotation	±90°
H-Tail Swing	0.6ft
Max. Working Slope	5°
Max. Wind Speed	28mph

Battery	48V/315Ah Li-ion battery
Charger	48V/60A
Drive Motor	AC 32V
Lift Motor	AC 32V
Auxiliary Power	12V DC Electrical pump
Hydraulic Tank Capacity	7.9 (us gal)

Type	33×12 Foam-filled tire

Gross

16093lb

Standard

Proportional control

All motion alarm

Flashing beacon

Self-closing entry gate

Emergency descent system

Emergency stop button

Auto-leveling system

On-board diagnostic system

Over tilt protection system

Oscillating axle (ZA20JE)

Load sensing system

4.3' LED display

Horn

Option

AC power to platform

Airline to platform

2.44×0.91m/8ft×2.98ft work platform（ZA20JE）

Non-marking tire
