World's top concept, features comfortable driving and mart operation
High pressure common rail high-end diesel engine
40F+40R interval power shift gearbox
APS automatic shift, differential lock, four-wheel drive, clutch switch etc.
Multi-disc hydraulic brake system
Whole machine all-electric hydraulic control system
Optional GPS navigation and driverless function
This model adopts world's top concept, features comfortable driving and smart operation;
All indexes and performances meet the European technical standards;
Integrated the resources of the world's top parts suppliers;
High pressure common rail high-end diesel engine that meets European emission standards;
40F+40R interval power shift gearbox with automatic shifting kinetic energy in the interval,the gearboxis provided with 40 km/h economic mode;
The gearb ox has the function of power reversal, which can switch between forward gear and backwardgear directly without depressing the clutch pedal;
World's advanced power management system, which can control multiple engine operating modes (fieldmode, PTO mode, etc.).
High torque reserve (33%) to match different PTO output of agricultural equipment.
APS automatic shift, differential lock, four-wheel drive, clutch switch and other functions can beautomatically controlled by computer;
Multi-disc hydraulic brake system.
Be provided with whole machine all-electric hydraulic control system with the function of fault selfdiagnosis;
The Armrest control armrest integrates engine, gearbox, farm implement control, engine speed cruisefield management and other functions;
Differential lock, 4WD, clutch control and other functions are integrated into computer automatic control,Automatic instrument display of all functions can be realized, with operation by touch screen andbuttons;
Automatic PTO, with automatic disengagement/engagement of the PTO clutch when lifting.
Closed Load Sensing, Variable Pump and other systems, greatly improving the operating efficiency andeconomy.
Optional GPS navigation and driverless function.
Optional front PTO, front suspension, front hydraulic output, power beyond3 class rear traction hitch.
Model | Unit | PL2304 |
Overall dimension (L×W × H) | mm | 6231×2575×3400 |
Wheelbase | mm | 3085 |
Minimum mass during operation | kg | 8995 |
Minimum ground clearance | mm | 420 |
Engine emission | / | National III |
Rated power | kW | 169.5 |
Fuel consumption rate | g/kW·h | ≤228 |
Cluth type | / | Multi-disc wet |
Number of gears of the gearbox | / | 40F+40R |
Tyre size (front wheel / rear wheel) | / | Wide wheels: front wheel540/65R30 rear wheel 650/65R42 Double row wheels: front wheel 420/90R30 rear wheel 520/85R42 |
Type of hydraulic lifting system | / | Split type |
Maximum lifting capacity | kN | 90 |
Tillage control method | / | Hydraulic control |
Hydraulic output multiway valve | / | Three position electro-hydraulic proportiona multi way valve |
Hydraulic hitch | / | Three-point rear suspension, Class III |
Hydraulic output flow rate | L/min | 110/160 |
Traction force | kN | ≥74 |
PTO output power | r/min | 540E/1000N/1000E;1000(front PTO) |
Cab | / | Air conditioning cab |
